Specifications

Motherboard

eATX, ATX, µATX

Drive Bays

5.25" external: 8

3.5" external: 1

3.5" internal: 0*

Front Connectors

USB 3.0: 1

USB 2.0: 2

Cooling System

Front: 2x 80mm or 1x 120mm or 1x 140mm

(optional)

Rear: 1x 120mm

(included, 3pin connector)

Controls

Power-Switch

Reset-Button

LED

1x Power-LED

1x Error-LED

6x HDD-LED

Power Supply

PS2/Mini Redundant PSU

ATX PSU

Material

1.0mm Steel

Packing Units

Shipping Unit: 1 Piece

Pallet: 12 Pieces

Guarantee and Warranty

Case 24 Months Warranty

Article Number

EAN-Code

88887064

4260133125155

Scope of Delivery

7x reuseable slot brackets

4x 5.25" EMC drive shields

4x slot card blank holder

2x 5.25" to 3.5" HDD adapter

3pin to 4pin fan adapter

ATX psu frame

Screw Set

Lock Loop

Stands

Keys

Features

Dust filters for 3x 5.25" bays

Flexible slot card holder

Front door lockable

Integrated speaker in the front

USB 3.0 and USB 2.0 as block connector

As 5U rack useable

(with the optional conversion kit Art. 88887068)

*only with included 5.25" to 3.5" adapter possible

Dimensions and Weight

Cage

Case

Package

Height

430mm

550mm

Width

220mm

340mm

Depth

530mm

595mm

700mm

Weight (net): 11.87 Kg

Weight (gross): 15.41Kg

Errors excepted. No warranty for the correctness of the information State:: 05.11.2013

Certification:

Power Supply

Connector

Quantity

Max. Length

Mainboard 20+4Pin

P4 12V 4Pin

P4/EPS 4+4Pin

P8 12V 8Pin

PCI-Express 6+2Pin

PCI-Express 6Pin

IDE 4Pin

S-ATA

Floppy

RPM sensor cable

Fan Control

Fan: 120mm

1 2

Certification: 2
